5001 Series - Bowed Internal Rings

DEFAULT SPECIFICATIONS

Brand HJ Tech
Standard 5001 Series
Material 65Mn/50#  SS301/SS304/SS316
Finish

Zinc/Black

Size 5001-025---5000-175
Industry Equivalents  BHO;MS16629;1301;3001





5001 Series - Bowed Internal Rings

Description:



Part Number Application Diameter (B) Groove Diameter (G) Groove Width (W) Groove Depth Ring Diameter (D) Ring Thickness (t) Ring Radial Wall (b) Ring Weight (1000 pcs)

5001-025

0.250

0.268

0.030

0.009

0.280

0.015

-

0.080

5001-031

0.312

0.330

0.030

0.009

0.346

0.015

-

0.110

5001-037

0.375

0.397

0.040

0.011

0.415

0.025

-

0.250

5001-043

0.438

0.461

0.040

0.012

0.482

0.025

-

0.370

5001-045

0.453

0.477

0.040

0.012

0.498

0.025

-

0.430

5001-050

0.500

0.530

0.055

0.015

0.548

0.035

-

0.700

5001-051

0.512

0.542

0.055

0.015

0.560

0.035

-

0.770

5001-056

0.562

0.596

0.055

0.017

0.620

0.035

-

0.860

5001-062

0.625

0.665

0.055

0.020

0.694

0.035

-

1.000

5001-068

0.688

0.732

0.055

0.022

0.763

0.035

-

1.200

5001-075

0.750

0.796

0.055

0.023

0.831

0.035

-

1.300

5001-077

0.777

0.825

0.062

0.024

0.859

0.042

-

1.700

5001-081

0.812

0.862

0.062

0.025

0.901

0.042

-

1.900

5001-086

0.866

0.920

0.062

0.027

0.961

0.042

-

2.000

5001-087

0.875

0.931

0.062

0.028

0.971

0.042

-

2.100

5001-090

0.901

0.959

0.062

0.029

1.000

0.042

-

2.200

5001-093

0.938

1.000

0.062

0.031

1.041

0.042

-

2.400

5001-100

1.000

1.066

0.062

0.033

1.111

0.042

-

2.700

5001-102

1.023

1.091

0.062

0.034

1.136

0.042

-

2.800

5001-106

1.062

1.130

0.070

0.034

1.180

0.050

-

3.700

5001-112

1.125

1.197

0.070

0.036

1.249

0.050

-

4.000

5001-118

1.181

1.255

0.070

0.037

1.319

0.050

-

4.300

5001-125

1.250

1.330

0.070

0.040

1.388

0.050

-

4.800

5001-131

1.312

1.396

0.070

0.042

1.456

0.050

-

5.000

5001-137

1.375

1.461

0.070

0.043

1.526

0.050

-

5.100

5001-143

1.438

1.528

0.070

0.045

1.596

0.050

-

5.800

5001-145

1.456

1.548

0.070

0.046

1.616

0.050

-

6.400

5001-150

1.500

1.594

0.070

0.047

1.660

0.050

-

6.500

5001-156

1.562

1.658

0.100

0.048

1.734

0.062

-

8.900

5001-162

1.625

1.725

0.100

0.050

1.804

0.062

-

10.000

5001-175

1.750

1.858

0.100

0.054

1.942

0.062

-

10.300
